Geotechnics

Our geotechnical area offers you geotechnical systems and their accessories for temporary and permanent use. Due to the high degree of prefabrication of our systems, we are able to implement your individual wishes quickly, inexpensively and with high quality.

TO THE APPROVALS


BBV temporary strand anchor

The BBV strand anchor systems for temporary and extended use are supplied ready for installation in accordance with DIN EN 1537 and DIN SPEC 18537. Due to the existing special systems, the BBV strand anchors meet the diverse geotechnical requirements.

BBV permanent strand anchor

BBV permanent strand anchors are manufactured in accordance with the approval requirements. The anchor is pre-injected at the factory both in the area of the free anchor length and in the area of the grouting section.

BBV micropiles

BBV single bar post

BBV micropiles are manufactured with simple and additional corrosion protection after approval. Constructional approved structural steels with thread ribs B 500 B for Ø 28 mm, Ø 32 mm, Ø 40 mm and Ø 50 mm are used as support members. The BBV micropile Ø 57.5 and 63.5 mm has a steel bar with thread ribs S 555/700.

BBV soil nails

BBV soil nails can be supplied as short-term and permanent soil nails. The additional corrosion protection coating of the permanent ground nails is applied at the factory after approval. Ribbed reinforcement steel BSt 500S (Ø 16 mm, Ø 20 mm, Ø 25 mm, Ø 28 mm, Ø 32 mm, Ø 40 mm and Ø 50 mm) is used as the steel tendon.
